BRIKtile
Comparison b/w Conventional & BRIKtile Wall System
Conventional Wall Construction System
Materials Brick, cement, sand, water, putty, paint, ceramic tile, tile adhesive
Manpower Brick mason, plaster mason, putty, painter, tile work mason
Time For construct 05 layers + reinforcement unit fixing + services lines fixing
Space 230mm (brick) + 35mm (plaster both side)+2 mm (putty+ paint) +15mm (tile backing )+ 8mm (tile) =290 mm wall thickness
Cost All materials + manpower ( approx. Cost 2700 3900 rs./sqm)
Environment GH emission through Brick, cement, putty, paint & tile production
BRIKtile -Smart Wall Construction System
Materials BRIKtile blocks, adhesive
Manpower Wall mason only
Time For 01 layer only (reinforced unit & supply line fixing simultaneously) (05 X less time)
Space 230 mm wall block (20% less thick) Around 5% more carpet area
Cost Around 50% less cost (approx. 1500-1800 rs./sqm)
Environment 5 -6 times lessGH emission
